High-level performance without the high price From large workloads to multitasking, the compact ThinkStation P520c breezes through it all. With cutting-edge processing, graphics, storage, and memory, this configurable 25L workstation is a solid workhorse. Energy efficient and extremely reliable, it's also ISV-certified and VR-ready. Equally impressive is the affordable price tag.
Real power at a reasonable price
For true processing power and blazing-fast visuals, power up the ThinkStation P520c. Fueled by the latest Intel® Xeon® processors and NVIDIA® Quadro® graphics, this compact 25L workhorse can help you to get the job done, quickly and easily. What's more, it comes at a very affordable price.
Configurable and reliable
The P520c can be configured to meet your specific needs, including up to 128 GB of memory and solid-state or hard disk drive storage options. One thing you won't have to worry about, however, is reliability, which is the cornerstone of every ThinkStation.
Enhanced flexible design
With two M.2 PCIe solid state drive slots embedded in the motherboard, you can enjoy blistering-fast storage speeds. What's more, the front FLEX module gives you a range of options and flexibility, including a media card reader and blazing-fast Intel® Thunderbolt™ 3 port.
Hassle-free, tool-free
Should you ever need to swap any components, there’s no need to worry about tools. Simply slide off the side panel and away you go. You may also wish to know that we can help automate many of the manual tasks associated with deploying new machines, from asset tagging to custom image loading.
Ready for anything, real or virtual
With virtual reality (VR), almost anything's possible—from revolutionary designs to stunning special effects to highly complex simulations. With the powerful P520c and top-of-the range, high-performance NVIDIA Quadro® graphics (optional), a truly immersive VR experience awaits.
Built-in peace of mind
Like every ThinkStation before it, the P520c has undergone rigorous testing under extreme conditions. It's also ISV-certified and boasts error-correcting code (ECC) memory, ensuring even greater accuracy and reliability.
A helping hand when you need it
You’ll be able to keep your P520c running at its peak thanks to Lenovo Workstation Diagnostics. Available for both desktop and smartphone, this intelligent app can help you diagnose and troubleshoot potential system issues by providing step-by-step guidance on optimal system performance. And should your machine ever fail to boot, an error code for additional assistance will be sent wirelessly to your smartphone.
In addition, there's Lenovo Performance Tuner. Free to download and easy to use, this software can help you fine-tune your workstation to get even more out of it.
Better for the planet—and your bottom line
The P520c meets some of the world's most comprehensive environmental standards. A GREENGUARD®-certified workstation, it has also been rated EPEAT Gold, ENERGY STAR 6.1, and up to 80 PLUS® Platinum PSU. And as a result of its energy efficiency, the P520c can even help lower your utility bills.
Product Specifications
Manufacturer
LENOVO TOPSELLER WORKSTATION
Manufacturer Part Number
30BX00G1US
Barcode
0196379911426
Brand Name
Lenovo
Product Name
Lenovo ThinkStation P520c Intel Xeon W W-2245 32 GB DDR4-SDRAM 1 TB SSD Windows 11 Pro for Workstations Tower Workstation Black
Mfr. Part Number
30BX00G1US
Barcode
0196379911426
Processor
Processor manufacturer
Intel
Processor family
Intel Xeon W
Processor model
W-2245
Processor cores
8
Processor boost frequency
4.5 GHz
Processor frequency
3.9 GHz
Processor cache
16.5 MB
Number of processors installed
1
Memory
Internal memory
32 GB
Internal memory type
DDR4-SDRAM
Memory slots
4x DIMM
ECC
Yes
Storage
Total storage capacity
1 TB
Storage media
SSD
Optical drive type
No
Number of storage drives installed
1
Total SSDs capacity
1 TB
Number of SSDs installed
1
SSD capacity
1 TB
SSD interface
PCI Express 3.0
NVMe
Yes
SSD form factor
M.2
Card reader integrated
Yes
Graphics
Discrete graphics card
No
Discrete graphics card model
Not available
Performance
Motherboard chipset
Intel® C422
Password protection
Yes
Password protection type
Power on
Trusted Platform Module (TPM)
Yes
Product type
Workstation
Network
Ethernet LAN
Yes
Ethernet LAN data rates
10,100,1000 Mbit/s
Cabling technology
10/100/1000Base-T(X)
Wi-Fi
No
Bluetooth
No
Ports interfaces
USB 2.0 ports quantity
2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
6
Ethernet LAN (RJ-45) ports
1
Headphone outputs
1
Line-out
Yes
Line-in
Yes
Microphone in
Yes
DVI port
No
PS/2 ports quantity
2
Power
Power supply
625 W
Power supply input voltage
100 - 240 V
Power supply input frequency
50 - 60 Hz
Design
Chassis type
Tower
Volume
25 L
Product colour
Black
Software
Operating system architecture
64-bit
Operating system language
English
Operating system installed
Windows 11 Pro for Workstations
Processor special features
CPU configuration (max)
1
Audio
Audio chip
Realtek ALC662
Audio system
High Definition Audio
Operational conditions
Operating temperature (T-T)
10 - 35 °C
Storage temperature (T-T)
-10 - 60 °C
Operating relative humidity (H-H)
10 - 80%
Operating altitude
-15.2 - 3048 m
Weight dimensions
Width
175 mm
Depth
426 mm
Height
376 mm
Weight
14.5 kg
Packaging content
Mouse included
Yes
Keyboard included
Yes
Brand
Lenovo
Availability
In Stock
Price Currency
USD
Category
Desktops Workstations
