Prices shown in USD. Taxes, duties and freight are quoted separately. Call 571-485-8682 for volume pricing.
| Manufacturer | Startech.com |
|---|---|
| Manufacturer Part Number | SV231DPUCA |
| Barcode | 065030872201 |
| Brand Name | StarTech.com |
| Product Model | SV231DPUCA |
| Product Name | StarTech.com 2-Port USB-C KVM Switch, Single 4K 60Hz DisplayPort Monitor, 3.5mm Audio, 6x USB Hub Ports, Hot Key Switching, Thunderbolt 3/4 Compatible - TAA |
| Marketing Information |
This 2 Port USB C KVM Switch toggles between two computers with one DisplayPort monitor using USB-C host connections - Supports up to 4K 60Hz (4:4:4) with 2x USB-A 2.0 hub ports; Supports ultrawide monitors - Featuring analog and digital audio this KVM switch easily integrates into an existing setup; USB-C Host connection means fewer cables for rapid deployment - Hotkey or Push Button Switching; 4x USB HID Ports; USB4/TB3/TB4 Compatible; OS Independent; TAA Compliant; 2-year Warranty
|
| Packaged Quantity | 1 |
| Mfr. Part Number | SV231DPUCA |
|---|---|
| Barcode | 065030872201 |
| Product Model | SV231DPUCA |
| Packaged Quantity | 1 |
| Ports interfaces | |
| Number of computers controlled | 2 |
| Keyboard port type | USB |
| Mouse port type | USB |
| Video port type | DisplayPort |
| DisplayPort version | 1.2 |
| Console ports | 3.5mm headphone, 3.5mm mic, DisplayPort |
| Console USB ports quantity | 6 |
| Console DisplayPorts ports quantity | 1 |
| USB hub | Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A hub ports quantity | 2 |
| Headphone outputs | 1 |
| Number of microphone inputs | 1 |
| Performance | |
| HD type | 4K Ultra HD |
| Maximum resolution | 5120 x 1440 pixels |
| Video bandwidth | 60 Hz |
| Data transfer rate (max) | 5 Gbit/s |
| Scan interval | 3,8,15,30 s |
| HDCP | Yes |
| Chipset | Parade - PS8461, Etron - EJ899I |
| Audio channels | 2.0 |
| Number of displays supported | 1 |
| Design | |
| Rack mounting | No |
| Product colour | Black |
| LED indicators | Yes |
| Push button | Yes |
| Hot keys | Yes |
| Mean time between failures (MTBF) | 158000 h |
| Display | |
| Built-in display | No |
| Power | |
| Power source | AC |
| Input voltage | 100 - 240 V |
| Input current | 1.2 A |
| Output voltage | 12 V |
| Output current | 3 A |
| Power plug type | Type M |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -10 - 60 °C |
| Operating relative humidity (H-H) | 0 - 80% |
| Weight dimensions | |
| Width | 140 mm |
| Depth | 160 mm |
| Height | 40 mm |
| Weight | 600 g |
| Packaging data | |
| Package width | 186 mm |
| Package depth | 240 mm |
| Package height | 94 mm |
| Package weight | 1 kg |
| Packaging content | |
| Quick installation guide | Yes |
| AC adapter included | Yes |
| Rubber feet | Yes |
| Other features | |
| IP control | No |
| Logistics data | |
| Master (outer) case width | 300 mm |
| Master (outer) case length | 397 mm |
| Master (outer) case height | 257 mm |
| Products per master (outer) case | 6 pc(s) |
| Brand | StarTech.com |
| Availability | In Stock |
| Price Currency | USD |
| Category | Monitors Displays |
