Extended Temperature| 15kV Air | 8kV Contact | Metal | Mountable | DIN Rail | 480 Mbps
This TAA compliant 4-port industrial USB 2.0 hub gives you the scalability you need in harsh industrial environments, product and repair labs, conference rooms or office workstations. With its rugged industrial grade metal housing, it is designed to meet the advanced requirements of connecting a high number of devices in factories and office environments.
Perfect for Harsh Environments
This industrial USB hub delivers reliable performance with a metal, heavy-duty housing. It supports wide-range 7-48V DC terminal block input, giving you the flexibility to power the hub as required, based on your own power input capabilities.
Perfect for more extreme environments, the rugged hub also supports a wide operating temperature range (-40°C to 85°C) and offers ESD protection to each USB port, which can help prevent damage to your connected devices.
Connect More USB Devices
Designed for a high volume of connections, this robust USB 2.0 hub offers four connection ports, for connecting more USB devices and peripherals.
Locate the Hub Where You Need It Most
With versatile installation options, you can install the hub where it’s best suited for your environment. With built-in mounting brackets, included DIN mount rails, and an included 2-meter USB host cable, you can securely mount the USB 2.0 hub to most surfaces such as a wall, under a desk or rack.
StarTech.com offers an external power adapter, ITB20D3250, sold separately. The universal DC power adapter can be used as an alternative, back up or replacement power supply for StarTech.com’s line of industrial USB hubs.
Works with Older USB Devices
The rugged USB hub supports the full 480 Mbps bandwidth of USB 2.0 and is backward compatible with previous USB devices.
The HB20A4AME is backed by a StarTech.com 2-year warranty and free lifetime technical support.
Product Specifications
Manufacturer
STARTECH.COM
Manufacturer Part Number
HB20A4AME
Barcode
0065030878623
Brand Name
StarTech.com
Product Model
HB20A4AME
Product Name
StarTech.com 4-Port USB 2.0 Hub - Metal Industrial USB-A Hub with ESD 350W Surge Protection - Extended Operating Temp -40 to 185°F - Din Rail/Wall/Desk Mountable - USB Expander Hub - TAA
Marketing Information
Protects your connected devices with 15kV Air and 8kV Contact ESD protection - Surge protection of 350W on the downstream and upstream USB ports - Mount industrial USB hub where required with built-in mounting brackets or included DIN rails - Offers flexible, wide-range power inputs with a 7-48V DC terminal block - Adds four industrial USB 2.0 ports from a single USB connection
Packaged Quantity
1
Mfr. Part Number
HB20A4AME
Barcode
0065030878623
Product Model
HB20A4AME
Packaged Quantity
1
Ports interfaces
Host interface
USB 2.0 Type-B
Hub interfaces
USB 2.0
USB 2.0 ports quantity
4
Ports quantity
4
Card reader integrated
No
Terminal block port
Yes
DC-in jack
No
Features
Data transfer rate
480 Mbit/s
Product colour
Black
Housing material
Metal
Surge protection
Yes
LED indicators
Power
Plug and Play
Yes
Certification
CE, FCC, TAA, RoHS, REACH
Power
Power consumption (typical)
14 W
Input voltage
7 - 48 V
Input current
2 A
Weight dimensions
Width
55 mm
Depth
95 mm
Height
32 mm
Weight
292 g
Packaging data
Package width
168 mm
Package depth
244 mm
Package height
55 mm
Package weight
504 g
Packaging content
Cables included
USB
Manual
Yes
DIN rail kit included
Yes
Operational conditions
Operating temperature (T-T)
-40 - 85 °C
Storage temperature (T-T)
-40 - 85 °C
Operating relative humidity (H-H)
5 - 95%
Logistics data
Master (outer) case width
440 mm
Master (outer) case length
530 mm
Master (outer) case height
340 mm
Products per master (outer) case
25 pc(s)
Harmonized System (HS) code
84719000
Other features
Chipset
Genesys Logic - GL852GT
Brand
StarTech.com
Availability
In Stock
Price Currency
USD
Category
Licenses Renewals
