| Manufacturer | Startech.com |
|---|---|
| Manufacturer Part Number | ST121HD20L |
| Barcode | 065030882637 |
| Brand Name | StarTech.com |
| Product Model | ST121HD20L |
| Product Name | StarTech.com HDMI over CAT6 Extender - 4K 60Hz - 330 ft. (100 m) - TAA |
| Marketing Information |
HDMI over CAT6 extender maintains astonishing 4K picture quality up to 330ft / 100m away over CAT6 cabling - Supports all known HDMI audio formats including Dolby True HD, Dolby Digital DTS-HD for a complete AV experience - Extend your 4K HDMI signal in offices, shopping centers, airports more. HDMI over Ethernet extender can optimize the placement of your demo stations at tradeshows - Ensured compatibility with HDCP 2.2 lets you enjoy the full capabilities of your HDMI equipped devices.
|
| Packaged Quantity | 1 |
| Mfr. Part Number | ST121HD20L |
|---|---|
| Barcode | 065030882637 |
| Product Model | ST121HD20L |
| Packaged Quantity | 1 |
| Features | |
| Type | AV transmitter receiver |
| Maximum resolution | 3840 x 2160 pixels |
| Cable types supported | Cat6 |
| Maximum transfer distance | 140 m |
| Chipset | Norelsys NS 5730, NS5731 |
| Maximum refresh rate | 60 Hz |
| Audio output channels | 7.1 channels |
| LED indicators | Link, Power |
| Supported graphics resolutions | 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 2560 x 1600 (WQXGA) |
| HDCP | Yes |
| Material | Metal |
| HDCP version | 1.4/2.2 |
| Product colour | Black |
| Ports interfaces | |
| Connectivity technology | Wired |
| RJ-45 input ports | 1 |
| RJ-45 output ports | 1 |
| HDMI in | 1 |
| Number of HDMI outputs | 1 |
| Serial ports quantity | 2 |
| Remote (IR) input | 2 |
| Remote (IR) output | 2 |
| DC-in jack | Yes |
| Power | |
| AC input voltage | 110 - 240 V |
| Operating voltage | 5 V |
| Output current | 2 A |
| External power adapter | Yes |
| Power plug type | Type M |
| Operational conditions | |
| Operating temperature (T-T) | -5 - 40 °C |
| Storage temperature (T-T) | -15 - 55 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Weight dimensions | |
| Width | 111 mm |
| Depth | 76 mm |
| Height | 26 mm |
| Weight | 271 g |
| Packaging data | |
| Package width | 250 mm |
| Package depth | 201 mm |
| Package height | 99 mm |
| Package weight | 1.42 kg |
| Packaging content | |
| AC adapter included | Yes |
| Cables included | LAN (RJ-45) |
| Included power plug types | ANZ, EU, JP, NA, UK |
| Quick start guide | Yes |
| Mounting brackets included | Yes |
| Logistics data | |
| Master (outer) case width | 420 mm |
| Master (outer) case length | 500 mm |
| Master (outer) case height | 280 mm |
| Products per master (outer) case | 10 pc(s) |
| Brand | StarTech.com |
| Availability | In Stock |
| Price Currency | USD |
| Category | Cables Connectivity |
