This multi-input converter switch lets you connect your DisplayPort (DP), HDMI® and VGA audio/video sources to one HDMI display or projector. The switch enables you to automatically or manually switch between your video sources and features built-in signal conversion, which eliminates the cost and hassle of using additional adapters for the sake of compatibility.
This versatile A/V switch supports video resolutions up to 1920x1200 (1080p) on your VGA source and up to 4K at 30 Hz on your DisplayPort and HDMI video sources. For a tidy, professional installation, the converter switch includes mounting hardware.
Save time with a single switch for DisplayPort, HDMI and VGA The A/V switch features built-in HDMI conversion, so you can connect two HDMI sources as well as a VGA and a DisplayPort video source to the same HDMI display, without having to use additional adapters or scalers.
Effortless control with automatic or priority switching The converter switch ensures hassle-free operation, with two different auto-switching modes: auto-detect switching, which detects and selects a newly connected device, or priority selection, which lets you choose which port should be activated by default for automatic switching. The converter switch is perfect for digital signage applications where an automatic switch can replace a failed source with a secondary input to avoid embarrassing video outages.
Focus on your presentation, not boardroom connections This versatile A/V switch has been designed with the boardroom and classroom in mind, with HDMI, VGA and DisplayPort inputs to support a wide range of devices, and a built-in converter that makes it easy to connect to the room’s display without having to connect additional adapters. Plus, automatic switching encourages on-the-fly collaboration among students or co-workers, by making it so easy to share a projector or other display device between multiple sources.
Impressive DisplayPort and HDMI image quality with 4K support The video switch maintains Ultra HD 4K picture quality while switching between content from HDMI and DisplayPort source devices, including Blu-ray™ players and DVD players, computer systems, video game consoles, digital cable and satellite boxes and A/V receivers.
4K video support ensures a higher level of image clarity and visibility, delivering four times the resolution of 1080p -- 8.29 million pixels versus 2.07 million pixels. It offers a more engaging visual experience for audiences in a wide range of venues, including conference centers, boardrooms, educational facilities, and commercial settings.
When connecting a VGA source, the switch supports high-definition resolutions up to 1920 x 1200. With its exceptional resolution and image quality, this switch is ideal for bringing your digital signage to life.
The HDVGADP2HD is backed by a 2-year StarTech.com warranty and free lifetime support.
Product Specifications
Manufacturer
STARTECH.COM
Manufacturer Part Number
HDVGADP2HD
Barcode
0065030863476
Brand Name
StarTech.com
Product Name
StarTech.com Multi-Input to HDMI Automatic Switch and Converter - 4K
Mfr. Part Number
HDVGADP2HD
Barcode
0065030863476
Ports interfaces
Video port type
HDMI/VGA/DisplayPort
HDMI in
2
Number of HDMI outputs
1
VGA (D-Sub) ports quantity
1
DisplayPorts quantity
1
DC-in jack
Yes
Features
Product colour
Black
Maximum refresh rate
60 Hz
Supported graphics resolutions
1024 x 768 (XGA), 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 2560 x 1440, 2560 x 1600 (WQXGA), 3840 x 2160
LED indicators
Status
Maximum resolution
3840 x 3160 pixels
Audio output channels
7.1 channels
Power
AC adapter input voltage
100 - 240 V
AC adapter output voltage
12 V
AC adapter output current
1.5 A
Power plug type
Type M
Certificates
Certification
CE, FCC, TAA, REACH
Weight dimensions
Width
105 mm
Depth
161 mm
Height
41 mm
Weight
615 g
Packaging data
Package width
296 mm
Package depth
211 mm
Package height
65 mm
Package weight
1.2 kg
Packaging content
Quick start guide
Yes
Remote control included
Yes
Cables included
Phone (RJ-11)
AC adapter included
Yes
Mounting brackets included
Yes
Plug adapter type
NA, EU, UK, AU
Screws included
Yes
Operational conditions
Operating temperature (T-T)
0 - 40 °C
Storage temperature (T-T)
-10 - 60 °C
Operating relative humidity (H-H)
0 - 80%
Technical details
Audio support
Yes
Compliance certificates
RoHS
Logistics data
Harmonized System (HS) code
85176990
Brand
StarTech.com
Availability
In Stock
Price Currency
USD
Category
Network Switches
