Record DVI video to your computer, and embed a 3.5mm audio source, at 1080p 60fps resolution
This DVI to USB 3.0 video capture device records high-definition DVI video to your computer. With an aluminum enclosure, this device is built strong for fixed-location or on-the-go capture. It offers a separate 3.5 mm audio input for accompanying audio or voice-overs, and a DVI pass-through port for connecting a monitor to review the video as it’s captured.
Capture HD video at 1080p 60fps
Record 1080p video at 60fps (frames per second), to save your content so it can be shared, stored, or edited. Capture from security equipment, control rooms, medical, or other industrial DVI devices, directly to your computer.
Easy video recording on Windows and Mac
The included software makes recording easy. Using a widely adopted codec, videos saved in StreamCatcher™ work with almost any video player and require no converting or editing.
Live stream on Windows
On Windows, you can live broadcast your video over the internet, using Twitch™ or other third-party video streaming platforms, with the included software.
DirectShow compatibility on Windows
With this capture device, you’re not tied to the included software. You can record raw/lossless video using any third-party DirectShow™ compatible software, such as Open Broadcaster Software (OBS).
Capture video from HDMI®, VGA or DVI devices
This versatile DVI capture device works with HDMI to DVI and VGA to DVI adapters, so you can record video from an HDMI or VGA source.
The StarTech.com Advantage
Product Specifications
Manufacturer
STARTECH.COM
Manufacturer Part Number
USB32DVCAPRO
Barcode
0065030864855
Brand Name
StarTech.com
Product Name
StarTech.com USB 3.0 Capture Device for High-Performance DVI Video - 1080p 60fps - Aluminum - TAA
Mfr. Part Number
USB32DVCAPRO
Barcode
0065030864855
Performance
Product colour
Black, Silver
Internal
No
Host interface
USB 3.2 Gen 1 (3.1 Gen 1)
Video capture resolution (max)
1920 x 1080 pixels
Interface
USB Type-B
Chipset
Mstar MST3363CNK-170
Mean time between failures (MTBF)
504825 h
Housing material
Aluminium
Certification
CE, FCC, TAA
Video
Analog signal format system
NTSC, PAL 60, PAL M
Supported resolutions
1920 x 1080, 1280 x 720, 1024 x 768, 800 x 600
Maximum frame rate
60 fps
Audio
Audio support
Yes
Supported audio channels
2
File formats
Import video formats supported
H.264, MPEG4
Ports interfaces
USB port
Yes
USB connector type
USB Type-B
USB version
3.2 Gen 1 (3.1 Gen 1)
Audio (L/R) in
1
DVI-I ports quantity
2
Power
Power supply type
USB
Software
Windows operating systems supported
Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64
Mac compatibility
Yes
Mac operating systems supported
Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave
Operational conditions
Operating temperature (T-T)
0 - 40 °C
Storage temperature (T-T)
-5 - 40 °C
Operating relative humidity (H-H)
20 - 80%
Technical details
Compliance certificates
RoHS
Weight dimensions
Width
61.1 mm
Depth
92.2 mm
Height
24.3 mm
Weight
102 g
Packaging data
Package weight
462 g
Package height
52 mm
Package width
150 mm
Package depth
217 mm
Packaging content
Cables included
USB
Quick installation guide
Yes
Logistics data
Harmonized System (HS) code
85176990
Brand
StarTech.com
Availability
In Stock
Price Currency
USD
Category
Computers IT Hardware
