TP-Link Omada ES208G network switch Managed L2 Gigabit Ethernet (10/100/1000) Black

Name: TP-Link Omada ES208G network switch Managed L2 Gigabit Ethernet (10/100/1000) Black
Brand: TP-Link
SKU: ES208G
Price: 33.89 USD
Availability: InStock

Availability: In Stock Mfr. Part#: ES208G Model: ES208G

$36.38 Save 7% · $2.49

$33.89 USD

Prices shown in USD. Taxes, duties and freight are quoted separately. Call 571-485-8682 for volume pricing.

B2B Volume Pricing
Purchase Orders Accepted for Approved Accounts
Government Institutional Purchasing
Secure Checkout

Download brochure / datasheet

Product Details

Omada Cloud Essentials — A Free and Easy Cloud-Based Network Management

Omada Cloud Essentials is a free, easy-to-use version of the Omada Cloud-based Controller. It provides cloud-based centralized management and monitoring for the Omada networking system, covering access points, switches, and gateways, ideal for surveillance networks and small businesses.

Product Specifications

Manufacturer	TP-Link
Manufacturer Part Number	ES208G
Barcode	840460600293
Brand Name	TP-Link
Product Model	ES208G
Product Name	TP-Link Omada ES208G network switch Managed L2 Gigabit Ethernet (10/100/1000) Black
Marketing Information	Omada 8-Port Gigabit Easy Managed Switch PORT: 8x Gigabit RJ45 Ports SPEC: Desktop Steel Case and Fanless FEATURE: Integration with Omada SDN Controller and Omada Cloud Essentials, Flow Control, Loopback Detection, Port Isolation, Port Mirroring, LAG, VLAN, IGMP Snooping, QoS, Storm Control
Packaged Quantity	1

Management features
Mfr. Part Number	ES208G
Barcode	840460600293
Product Model	ES208G
Packaged Quantity	1
Switch type	Managed
Switch layer	L2
Quality of Service (QoS) support	Yes
Web-based management	Yes
Cloud-managed	Yes
Unified static configuration	Yes
Ports interfaces
Basic switching RJ-45 Ethernet ports quantity	8
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity	8
Network
Networking standards	IEEE 802.3ab, IEEE 802.1ab, IEEE 802.3i, IEEE 802.1p, IEEE 802.3x, IEEE 802.3at, IEEE 802.1Q
10G support	No
Zero Touch Provisioning (ZTP)	Yes
Port mirroring	Yes
Flow control support	Yes
Link aggregation	Yes
Auto MDI/MDI-X	Yes
Auto-negotiation	Yes
Fast leave	Yes
VLAN support	Yes
Virtual LAN features	MTU VLAN, Port-based VLAN, Tagged VLAN
Number of VLANs	32
Data transmission
Switching capacity	16 Gbit/s
Forwarding rate	11.9 Mpps
MAC address table	8000 entries
Store-and-forward	Yes
Jumbo frames support	Yes
Jumbo frames	15000
Packet buffer memory	4 MB
Security
DHCP features	DHCP client
IGMP snooping	Yes
Loop protection	Yes
Queue scheduling algorithms	Weighted Round Robin (WRR)
Design
Rack mounting	No
Stackable	No
Product colour	Black
LED indicators	Yes
Wall mountable	Yes
Performance
Flash memory	64 MB
Firmware upgradeable	Yes
Fanless	Yes
Mean time between failures (MTBF)	1141726 h
Power
Power source	DC
Power supply included	Yes
DC input voltage	5 V
Input current	0.6 A
Power consumption (max)	2.7 W
Surge protection	Yes
Surge protection voltage	6 kV
Power over Ethernet (PoE)
Power over Ethernet (PoE)	No
Operational conditions
Operating temperature (T-T)	-5 - 45 °C
Storage temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	10 - 90%
Storage relative humidity (H-H)	5 - 90%
Heat dissipation	9.09 BTU/h
Weight dimensions
Width	158 mm
Depth	100.7 mm
Height	25.4 mm
Packaging content
User guide	Yes
Packaging data
AC adapter included	Yes
Package type	Box
Certificates
Compliance certificates	CE, Federal Communications Commission (FCC), RoHS
Brand	TP-Link
Availability	In Stock
Price Currency	USD
Category	Network Switches
